Vehicle Tracking System
GPS Vehicle Tracking System for Business Intelligence
Pacific star enabled GPS vehicle tracking and Telematics system offers state of the art solutions which integrates moving vehicle control tools, effective remote vehicle data transfer, powerful logistic tool and low maintenance enabling organizations to carry out their business in an effective and cost effective manner by locating and reporting geographical information in real time. This system allows organizations to centrally manage and optimize their geographically dispersed field resources.
Our Automatic Vehicle Location Software provide fleet location management applications which helps improve emergency response and assist operations department with comprehensive historical reporting tools to identify cost savings and increase efficiencies. Emergency hand held locators enhance the safety of lone workers, children and elders.
Pacific Controls Telematics Module
Pacific Controls Telematics module is a terminal with GPS and GSM connectivity, which is able to determine the vehicle’s coordinates and transfer them via the GSM network. This device is perfectly suitable for applications where location acquirement of remote objects is needed. It is important to mention that module has additional inputs and outputs, which let you control and monitor other devices on remote objects. 1-Wire® interface (for Dallas digital thermometer or I-Button reader) and CAN interface integrated (for trucks FMS interface data acquisition). It also has a RS232 port for NMEA output and configuration.
In case of losing GSM network connection our device can store up to 8000 records (optionally 64000 records), and once the connection is established the device will send stored data via GPRS. So you won’t lose your data (coordinates, sensors data and ect.).
Features and Characteristics:
- Track your remote objects (trucks, cars, ships etc) quickly and easily.
- GPRS class 10 (up to 85,6 kbps);
- SMS (text/data);
- Quad-band GSM - 900 MHz / 1800 MHz; 850 MHz / 1900 MHz.
- The aluminum case of the device is very robust and perfectly suitable for installation into harsh environment such as cars, trucks, boats or other moving objects.
- Option of internal (or external) rechargeable battery with charge controller.
- FM4100 has 4 digital inputs, 4 digital outputs and 4 analogue inputs, which could be used for performing tasks on remote objects, such as monitoring fuel tank level, engine status, or controlling truck door etc.
- FM4100 has 1-Wire® I/O protocol integrated for temperature measuring or key ID identification.
- Pacific Controls firmware for the device enables such functions as:
- GPS and I/O, 1-Wire, CAN data acquisition
- External sensors connection capability
- Real Time tracking
- Smart algorithm of data acquisition (time and distance based)
- Sending acquired data via GPRS (TCP/IP and UDP/IP protocols)
- Smart algorithm of GPRS connections (GPRS traffic saving)
- Flexible configuration of data sending in roaming networks (depending on GSM providers list)
- Events on I/O detection and sending via GPRS or SMS.
- Scheduled 24 coordinates SMS sending
- Multi geofence zones (rectangular or circle)
- Sleep mode (saving vehicle’s accumulators)
